Home Products Processing Centricoater

Modern Coating Technology

Centricoaters

Modern Coating Technology

HIGHLIGHTS

  • Increased growth ability of seed.
  • Designed for coating value-added seeds with costly seed treatments.
  • Ensures continuous batch operation utilising a highly accurate inlet scale together with a highly accurate chemical dosing system controlled by a PLC.
  • Provides improved seed coverage and more uniform distribution of treatment material on the seed compared to traditional continuously operating drum or screw-type coaters.

Get a Quote

Download Brochures

Cimbria Centricoater

The Centricoater optimizes the consumption of chemical agents and the impact on the environment, by reducing the use of raw materials.

The results are homogenous coated seeds, which have improved growth ability and meet the international standards for certified seeds.

The smart use of the coating slurries reduces the processing costs, with a very short pay-off period for Cimbria Centricoaters.

Centricoater Animation Video

Product Overview

Centricoater Automatic

The “compact” Centricoater series is designed for easy installation at the customer’s site. Each Centricoater is pre-wired from the factory and delivered pre-tested. After connecting the grain pipes (for filling and discharging), main electric power supply, compressed air, dosing line piping and the prepared cables for each item – plug and play – the Centricoater is ready for operation.

Data Sheets

Cimbria Centricoater Automatic

Centricoater Semiautomatic

The “semiautomatic” series allows an easy entry to batch coating technology. Available with two drum sizes, this type is equipped with a PLC operated electrical panel with touch display. Automated scale is not part of the hardware. All other hardware (mixing drum, dosing line) are fully automated, enabling the automated coating of single batches.

Data Sheets

Cimbria Centricoater Semiautomatic equipment

Centricoater Lab

The standard lab-coaters are designed for the manual coating of small quantities of seeds in laboratories or breeding stations. All products and their quantities are prepared manually by the operator before filling into the lab-coater. The operator’s timing, filling and discharging of the mixing drum is all done manually.

Data Sheets

The Cimbria Centricoater Lab

Specifications

ModelMixing Drum SizeCapacity (referred to what)
CC1010 kgmax. 1,6 t/h
CC2025 kgmax. 4,1 t/h
CC5050 kgmax. 8,1 t/h
CC150150 kgmax. 13,5 t/h
CC250250 kgmax. 22,5 t/h
CC250DUO250 kg x2max. 45 t/h
CC20/50 L25/50 kgmax. 4,1 t/h
max. 8,1 t/h
CC LAB2 kg–
CC10 LAB10 kg–
CC10/20 – S10 kg–

Technical data can vary due to continued development or a different machine composition.
